20 Ton Amada Aeries-245 Turret Punch, 1990


Request a Quote to Instantly See Pricing

Machine Type: Turret Punches
Make: Amada
Model: Aeries-245
Year: 1990
Capacity: 20 Ton
Machine Location: California
Stock #: 491541

Punching Capacity: 22 US/20 Metric Tons
Max. Traverse: 39.37” X 50”
Max. Sheet Size(w/1 Reposition): 39.37X 100”
Max. Sheet Weight: 110 LBS.
Turret Configuration: 20 Stations
Turret Speed: 20 RPM
Strokes Per Minute: 300 SPM
Maximum Hit Rate (1” Pitch): 80 HPM
Maximum Feed Speed: 131 FPM
Power Required: 11 KVA
Machine Weight: 16,535 LBS

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
