242 ton x 12′ Primeline S250B12 CNC Press Brake, 2017 – 4 Axis Backgauge X,R,Z1/Z2, Very Clean
$79,900.00
This product is no longer available. For additional information, please fill out the form below.
Model: S250B12
Year: 2017
Overall Capacity-242 Ton X 12′
Operation Type: Cnc Control
Bending Length: 145″
Distance Between Columns: 120.40″
Open Height: 20.2″
Stroke: 10.24″
Throat: 15.75″
Table Height: 36.63″
Back Gauge Speed
X Axis Speed: 23.63 In/sec
R Axis Speed: 14.18 In/sec
Back Gauge Stroke: 29.54″
Rapid Approach Speed: 5.2 In/sec
Pressing Speed: 0.47 In/sec
Return Speed: 5.67 In/sec
Hydraulic Tank Capacity: 77 Gallons
Horsepower: 25 H.P.
Dimensions: 214.65″ X 106.34″ X 114.22″
Weight: 26400
Cybelec Control
Light Curtains
Backgauge 4 Axis (X, R, Z1/Z2)
