Dieci Pegasus 40.25 Telehandler, 2015

Performance:
Maximum Capacity: 4000kg (8818 lb)
Maximum lifting height on outriggers: 24.10m (79ft)
Maximum horizontal extension on outriggers: 20.50 m (67 ft)
Fork swiveling angle: 133°
Pull-out force: 5700 daN (12814 lbf)
Towing force: 9400 daN (21132 lbf)
Maximum climb angle: 40%
Unladen weight: 17500 kg (38581 lb)
Maximum speed: 40 km/h (24.9 mph)

Engine
Brand: FPT
Nominal Power: 96 kW (129 HP)
@rpm: 2200 rpm
Peak power: 105 kW (141 HP)
@rpm 1900 rpm
Operation: 4-stroke
Injection: Electronic, Common Rail
Number and arrangement of cylinders: 4, Vertical in line
Displacement: 4485 cm3 (274 in3)
Consumption: 208 g/kWh (342,16 lb/Hph)
@rpm: 1900 rpm
Emission standards: Stage IIIB/Tier 4i
Exhaust gas treatment: SCR (AdBlue)
Cooling system: Liquid
Intake: Turbo compressor 16 valve

Transmission:
Transmission type: Hydrostatic with variable flow pump
Hydraulic motor: Hydrostatic with continuous automatic adjustment
Reversal: Electrohydraulic
Inching: With inching pedal for controlled forward movement
Transmission gearbox: Servocontrolled 2-speed

Includes;
Fork, Winch, and Extendable Man Basket
