Donatoni Jet 625 5 Axis Bridge Style Stone Saw, 2020

Number of Interpolated Axes: 5
Carriage Stroke Axis X: 141.7 inches
Bridge Stroke Axis Y: 104.3 inches
Vertical Stroke of the Head Axis Z: 15.7 inches
Disc Head Rotation (Axis C) Degrees: -5° / 365°
Disc Head Tilting Movement (Axis A) Degrees: 0 / 90°
Working Table Dimensions: 94.4 x 149.6 inches
Minimum Disc Diameter: 15.7 inches
Maximum Disc Diameter: 24.6 inches
Max Cutting Depth: 7.87 inches
Electro Spindle Motor Power: 17.4 horsepower
Disc Rotation With Inverter: 2400 rpm
Tools Rotation With Optional Tools: 5500 rpm
Disc Motor Shaft Diameter: 1.9 inches
Max Speed Axis X: 0 – 131.2 feet/minute
Max Speed Axis Y: 0 – 98.4 feet/minute
Max Speed Axis Z: 0 – 16.4 feet/minute
Adjustable Cut Feeding Speed: 0 – 82 feet/minute
Water Consumption (3 Bar): 9.2 gallons/minute
Air Consumption: 5.2 gallons/minute
Standard Voltage: 400/50 volts/hertz
Max Disc With Suction Cups (Stroke 195 mm): 20.6 inches
Total Weight Max Lifting With Suction Cups: 661.3 pounds
