Hardinge Bridgeport XR760 VMC W/4TH Axis Tsuda Coma Rotary Table, 2010

X Axis Travel 30”
Y Axis Travel 24”
Z Axis Travel 24”
Table Size 35” x 23.6″
Max. Table Load 2,000 Lbs.
Spindle To Table Surface 3.94” – 27.9”
Spindle Motor 25 HP
Spindle Speeds 12,000 RPM
Spindle Taper CT 40
ATC 30 Bidirectional Side Mount
Rapids (XY/Z) 1,692/ 1,417 IPM
Machine Dimensions (Approx.) 155” x92”x 92”
Machine Weight (Approx.) 16,000 Lbs.

Equipped With:
Fanuc 18i-M CNC Control
12,000 RPM BIG-PLUS Spindle
Full 4th Axis Tsuda Coma Rotary Table
Chip Conveyor
Chip Blaster For Through Spindle Coolant
Rigid Tap
Mist collector
External Hydraulic unit for clamping
3 stage coolant filter
