Han’s G20 Laser Marking System, 2020 – Low Hours, Fume Extractor


This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:

Laser Type: MOPA Fiber Laser
Wavelength: 1064 nm
Min Beam Diameter: < 30 µm
Pulse Width Adjustment Ranges: 4ns, 8ns, 14ns, 20ns, 30ns,50ns, 100ns, 200ns
Pulse Frequency: 1.5 – 1000 KHz
Output Power: 20Watts Fiber
Repetition Accuracy: ±3μm
Cooling System: Air-cooled
Marking Field Size-F160: 3.93″ x 3.93″
Marking Field Size-F254: 6.29″ x 6.29″
Operation System: WINDOWS 7 or 10
Profile Laser: Visible, red-beam pilot laser for easy positioning of the workpiece
Electrical Connection: 110 – 230 V (± 10%) 6 A, 50/60 Hz
Power Consumed: 500W
Dimensions: 20.87″ x 27.95″ x 31.50″
Weight: 220 lbs

Equipped With:
– Model XL-300 Fume Extractor
– Remote
– Manual
