Strama MPS Welding Cell, 2013 – (2) Yaskawa MA1400 Robots, 2014


This product is no longer available. For additional information, please fill out the form below.

Dual Station Robotic Mig Welding Cells
Automated Control: Rexroth Indra Control VDP 40.3 SKS Q84 Weld Controllers
Overall Footprint: 20’x18′
Cell Opening: 12’X9′
Fixture/Max Part Size: 3 Meters
Integrated Dust Collection
Integrated Fire Suppression

(2) Yaskawa MA1400 Robots
Axes: 6
Payload: 3.00kg
H-Reach: 1434.00mm
Repeatability: +/- 0.0800mm
Robot Mass: 13.00kg
Structure: Articulated
Mounting: Floor, Inverted, Angle
DX100 Robot Controllers

Weld Positioners
Yaskawa RWV2 Series: 2 Station Positioner with Horizontal Rotary Axes
Payload: 2500kg
Height of tilt Axis: 2800-6000mm
Diameter Workpiece: 1600-2000mm

Welding Supply
(2) SKS LSQS Power Supplies
(2) SKS Torch Systems: Weld Guns/PF5 Power Feeders
(2) Nasarc/J Thielman Torch Cleaners
