Vanguard TPX6111B/3 Horizontal Boring Mill – 3 Axis DRO, Rotary Table

$19,900.00

This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:

Spindle Diameter: 4.33″
Spindle Taper: CAT 50
Worktable Travel: 35.43″ x 35.43″
Spindle Center Line to Worktable: 35.43 mm
Max. Spindle Travel: 23.62″
Max. Radial Facing Slide Travel: 7.1″
Max. Load on Table: 2500 kg
Spindle Speed Range: 8-1000 RPM (22 steps)
Radial Facing Slide Range: 4-200 RPM (18 steps)
Rapid Traverse Speed of Spindle: 98.43 in/min
Rapid Traverse Speed of Headstock: 98.43 in/min
Rapid Traverse Speed of Cross & Longitudinal Saddles: 98.43 in/min
Worktable Working Surface: 43.31″ x 37.8″
Rapid Speed of Rotary Table: 1 r/min
Measuring System Reading Accuracy: 0.0005″
Roughness of Boring Hole: 3.2-1.6
Dimensions: 193″ x 97″ x 108″
Weight: 28,700 lbs.

Equipped With:
3 Axis Newall DRO
Rotary Table
