Elumatec SBZ122 CNC Machining Center, 2005 – Needs Work

$54,900.00

Request a Quote to Instantly See Pricing

Call Now

Machine Type: Fabrication
Make: Elumatec
Model: SBZ122
Year: 2005
Machine Location: Upon Request
Stock #: 011505

Table Capacity X-Axis: 137.7″
Table Capacity Y-Axis: 13.75″
Routing Capacity Top: 9″
Routing Capacity Front: 7″
Table Capacity Z-Axis: 11″
Step Over Capacity: 7.3″
Rapid Positioning Y-Z Axes (max.): 1,176″/min
Rapid Positioning X-Axes (max.) 1,968″/min
Spindle Speed: 21,000 Rpm
Router Spindle: 8.1 Hp
Power Output: 480 Volt, 3 Phase
Profile Height/ste Over Max: 11″
Max. Diameter of Tooling: 2.4″
Max. Diameter of Disk Cutter: Manual 7.87″/automatic 3.62″
Max. Air Pressure 102 Psi
Max. Length of Tooling (top): 7.9″
Max. Dia. Shaft for Er-32 Collet. 78″
Max. Dia. Shaft for Er-16 Collet (angle Head Cap Collet): .511″
Max. Dia. Shaft for 077 Collet .394″
Tapping Capacity up To (w/float Collet-Er32 Collet Size): .375″ @65%
Thread Tool Chuck: Hsk F63 Tool Holder for Auto Tool Change
Dimensions: 62″x49.5″
Light Curtain Width: 181.3″l X 88″ H
Weight: 3,605 Lbs

Note: 7 K in Repairs Needed (list of Repairs Available)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
