Wobide AMGS1000 Heavy Duty Single Shaft Plastic Shredder With AMGH 800/600 Heavy Duty Plastic Crusher Equipped With 2 x Conveyor Belts + Silo Blower System + Control Panels


This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:

Belt width: 800mm
Conveyor length: 5000mm
Mating power: 3kw
Conveyor speed: 0-150rpm
Material: Rubber material and 45# carbon steel.


Capacity: 800-1000 K/h.
Model: AMGS1000
Rotor length: 1000mm
Rotor rotating diameter: 450mm.
Number of rotating knives: 63 pcs.
Number of fixed knives: 3 pcs.
Blade size: 40×40×25mm and material: D2.
Rotation speed: 78 RPM.
Motor power: 75 Kw.
Gearbox model: 207#
Hydraulic press power: 4kw
Feeding material size:1440×1030mm
Shredding room: 1000×1000mm
Number of motor belts: 4 belts
Screen size:50mm.
Discharging size from floor: 600mm.
Machine weight: 7000 Kg.
Machine dimension: 2880 x 2180 x 2580mm
Parts: two sets belts.

Conveyor #2

Width: 600mm
Length: 6000mm
Motor: 1.5kw
Material: PVC belt and 45# steel.

Plastic Crusher

Model: AMGH800/600
Infeed opening: 800X705mm
Rotor diameter: 600mm
Rotor width: 800mm
Screen size: 16mm
Fixed blade: 4pcs
Rotor blades: 10pcs
Main power: 55kw.
Hydraulic mower: 1.5kw
Machine size: 2100X1750X3200mm
Machine weight: 3500kg
Parts: 2 sets belts.
