65 Ton Scotchman 6509-24M Ironworker, 1998
$6,000.00
This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:
Punching Capacity: 65 Ton
Special Tooling: 4″ Maximum Diameter
Throat Depth: 9″
Flat Bar Shear: 24″ Length
1″ x 6″
3/4″ x 10″
3/8″ x 16″
1/4″ x 24″
Optional Saber Blade: 1″ x 8″
1/2″ x 16″
Angle Shear, 90 Degrees: 6″ x 6″ x 3/8″
45 Degrees: 3″ x 3″ x 3/8″
With Bar Shear: 4″ x 4″ x 1/2″
Brake 12″*: 40 Ton
Brake 24″*: 30 Ton
Pipe Notcher, Schedule: 40 I.D.*: 3/4″, 1″, 1-1/4, 1-1/2″, 2″
Rectangle Notcher: 2″ x 2-1/2″ x 3/8″
90 Degree V-Notcher: 6″ x 6″ x 5/16″
Channel Shear: 2″ to 5″ Adjustable
Rod Shear
Round Rod: 1/4″ to 1-1/4″, 9 Cavity
Square Rod: 1/4″ to 1″, 1 Cavity
Square Tube Shear: 1/2″ to 2″, 14 Gauge
Picket Tool Housing: 1/2″, 3/4″, 1″
Strokes Per Minute, Light Material: 40 SPM
Strokes Per Minute, Heavy Material: 17 SPM
Hydraulics: 2500 PSI
Motor: 5 HP, 3 Phase 208 V
230/460 volt /3 Phase Electrics (must specify voltage)
Dimensions: 24″W x 60″L x 66″H
Approximate Weight: 2750 Lbs.
