DMG MORI CMX 1100V VMC, 2017 – 12k RPM Spindle, TSC
$34,110.00
This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:
“2017 DMG Mori 1100V Vertical Machining Center
LNS CC Table
Working surface 55.12โ x 22.05โ
Loading capacity 2205 lbs
Travel
X-axis travel 43.31โ
Y-axis travel 22.05โ
Z-axis travel 20.08โ
Distance from table surface to spindle nose 4.72โ24.80โ
Spindle
Max. spindle speed: 12,000 RPM
Feedrate
Rapid traverse X/Y/Z 1417 / 1417 / 1181 IPM
Cutting Feedrate .04 โ 787 IPM
ATC
Tool interface: CAT40
Tool storage capacity: 30
Max. tool diameter
with adjacent tools 3.15โ
without adj. tools 4.9โ
Max. tool length 11.81โ
Max. tool weight 17.6 lbs
Tool changing time
Tool-to-tool s 1.32 /1.46
chip-to-chip s 3.70
Motor
Spindle Motor 20/15 HP
Machine size
Floor space widthรdepthxHeight 150ร108.54 x 115
Machine weight (net) 13,000 lbs
one owner machine”
Equipped With:
DMG Mori Slim Line Control
12,000 RPM Spindle
Chip Conveyor
Through Spindle Coolant
Coordinate System Rotation
Scaling
Cylindrical Interpolation
