Mazak VTC 200 B VMC, 2000
$16,900.00
This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:
Table Size: 57.48โณ x 20.08โณ
Table Load Capacity: 1760 lbs
Distance from Spindle Nose to Table Top: 7.09โmin./ 27.17โmax.
X Axis Travel: 44.09โณ
Y Axis Travel: 20.08โณ
Z Axis Travel: 20.08โณ
Rapid Traverse Rates (X,Y,Z): 1181 IPM
Magazine Capacity: 24 ATC
Chip-to-Chip / Tool-to-Tool Change Time: 4.7sec. / 1.5sec
Spindle Nose: #40
Spindle Speed: 10,000 RPM
Main Motor: 20 HP
Max. Tool Length / Weight: 13.78โ / 17.6 lbs.
Weight: 13,200 lbs estim.
Auto Tool Length
