¼ X 10’ Guifil GHD-630 Shear, 1987 – Backgauge, 13 Hold downs

Capacity: 10′ x 1/4″ mild steel
10′ x 9 ga. stainless steel
Length of knives: 122″
Distance between housings: 138″
Hold downs: 13
Rake angle: 1dg minimum
2.5dg maximum
Speeds approx.: 16 SPM @ maximum angle
50 SPM @ minimum angle
Floor to top of bed: 32″

EQUIPPED WITH:

29.52″ front-operated power back gauge with
control & readout
39″ squaring arm
Electric foot switch
Pushbuttons for start-stop
Blade gap adjustment via hand lever
Cutting length & cutting angle control
One set of extra blades
Approx. 1/2 HP back gauge motor
Hydraulic pump driven by
12 HP 1720 RPM 220/440/3/60 motor
Weight approx. 11,000 lbs.
Overall dimensions approx. 155″ L-R x 85″ F-B x 69.5″ H

One seal leaks
