150 Ton Sodick GL150A Injection Molding Machine, 2022

Clamping Unit:
Clamping System: Hybrid Direct Pressure
Max. Clamping Force: 150 Ton
Tie Bar Distance: 22″ x 20.4″
Platen Dimensions: 28.3″ x 26.7″
Open Daylight: 35.4″
Min. & Max. Mold Thickness: 9.9″ – 23.6″
Ejector Stroke: 4.72″

Injection Unit:
Screw Diameter: 1.26″
Plunger Diameter: 1.26″
Max. Injection Pressure: 34,809 PSI
Injection Rate: 19.6 inch/sec
Plunger Stroke: 5.3″
Max. Injection Speed: 19.69 inch/sec
Plasticizing Capacity (kg/h): 40
Max. Screw Revolution: 300 RPM
Nozzle Contact Force kN 15.7 15.7 19.6
Injection Unit Stroke: 14.35″

Machine Dimensions (LxWxH): 173.3″ x 54.3″ x 74.1″
Machine Weight: 11,100 LBS
