200 Liter Across International SR200 Jacketed Stainless Steel Reactor & Huber Unistat T320 with Pilot ONE, 2021 (Like New)

$59,900.00

Request a Quote to Instantly See Pricing

Call Now

Machine Type: Process Equipment
Make: Across International
Model: SR 200E.220
Year: 2021
Machine Location: Upon Request
Stock #: 726940

SR200 Jacketed 200L 316L-Grade SST Reactor:
Electric stirring motor: 220V, 50/60Hz, 1~Phase, 200 watts, 1/4 HP
Rotation: 450 rpm max. (±8%)
Port configuration: Lid: 12″ triclamp
Center motor port: 3″ triclamp
Drain port: 6″ triclamp
Drain port on/off valve: 2″ triclamp
Vacuum port: 1″ triclamp
Main vessel: Volume: 200L
Minimum fill volume: 40L
Material: 316L grade stainless steel
Temperature range: -55°C to +250°C (-67°F to +482°F)
Shipping Weight (Unit): 570 Lbs / 890 Lbs
Shipping Dimensions: 50″ x 40″ x 90″ (WxDxH)

Huber Unistat T320 With Pilot ONE:
Temperature range: 65…300°C
Dimensions (W x D x H): 21.26″ x 26.69″ x 46.22″
Weight: 432.18 Lbs
Pressure Pump Max.: 96 lpm ; 3.5 bar | 25.36 gpm ; 50.75 psi
Power supply: 380-460V, 3Ph, 50/60Hz

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
