45″ x 275″ Tacchi HD3 CNC Lathe – 36″ Chuck, 1992 – Steady Rests, Video Available

$54,900.00

Request a Quote to Instantly See Pricing

Call Now

Machine Type: CNC Lathes
Make: Tacchi
Model: HD3
Year: 1992
Machine Location: Upon Request
Stock #: 127482

Maximum Swing Over Bed: 45.27″
Maximum Swing Over Saddle: 31.49″
Distance Between Centers: 275.59″
Weight Between Centers Without Rests: 22,000 Lbs
Spindle Speeds: 2-720 Rpm
Number of Speed Ranges: 3
Main Motor: 80 HP
Spindle Nose: 11″
Spindle Hole Diameter: 4.13″
Longitudinal Feeds, Variable: 0-236 Ipm
Cross Feeds, Variable: 0-236 Ipm
Tailstock Quill Diameter: 5.51″
Tailstock Quill Travel: 11.81″
Internal Taper: Morse #6
Machine Dimensions:

Equipped With:
Siemens 810 CNC Control
4-Position Turret
36″ 4-Jaw Chuck
(3) Steady Rests
Chip Conveyor

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
