Brewhouse Tanks Package, 2022- (x2) 10 Bbl Tanks, (x1) 7 Bbl Tank, (x1) 10 Bbl Hot Liquor Tank, (x1) 5 Bbl Kettle, (x4) 5 Bbl Tanks

$229,900.00

Request a Quote to Instantly See Pricing

Machine Type: Stainless Steel Tanks
Make: DME
Model: Brewhouse Tanks
Year: 2022
Machine Location: Upon Request
Stock #: 614953

**More Information upon Request**
(2) Masterbrew 10 Bbl (12.5 Hl) Unitank – Custom:
Vessel Working Pressure: 15 Psi (1 Bar)
Jacket Working Pressure: 29 Psi (2 Bar)
Shell Material T304 Sa-240 2b S/S
Cladding Material T304 Sa-240 #4 S/S
Asme Style Head, 60-Degree Cone Bottom
Insulation Sides And Bottom
Bottom Fittings: Tc Drain, Din Racking Ferrule, Glycol Couplings
Relief Pressure 14.9 Psi, Relief Vacuum 3.4 Psi
(1) 7 Bbl Lauter Tun – No Rakes:
Design Pressure: Atmospheric
Shell Material T304 2b S/S, Cladding Material T304 #4 S/S
Side Fittings: Thermowell
Bottom Fittings: Wort Outlets, Wedge-Wire False Bottom
1.5in Wort Collection Header
Sparge Cap With Water Inlet
(1) 10 Bbl Hot Liquor Tank – Electric:
Design Pressure: Atmospheric
Shell Material T304 2b S/S
Cladding Material T304 #4 S/S
Shallow Cone Top, Shallow Cone Bottom
Insulation & Cladding On Sides And Bottom
(1) 5 Bbl Electric Kettle / Whirlpool:
Stainless Steel Kettle
Design Pressure: Atmospheric
Shell Material T304 Sa 240 2b S/S
Cladding Material T304 Sa 240 #4 S/S
Bottom Fittings: Drain
30 Kilowatt Element Mounted In The Side Of The Vessel Complete With High Temperature
Limit
20%, 40%, 60%, 80%, 100% Control Firing Of The Element
Kettle Pump
Washdown Duty Motor
(4) Masterbrew 5 Bbl (5 Hl) Unitank – Custom:
Vessel Working Pressure: 15 Psi (1 Bar)
Jacket Working Pressure: 29 Psi (2 Bar)
Shell Material: T304 Sa-240 2b S/S
Cladding Material: T304 Sa-240 #4 S/S
Interior Weld Finish: Ground Smooth, Polished On A Regular Margin And Acid Cleaned

**Potentially Can be Split**

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
