Deamco BEM‑09P‑SW‑X1 Solid‑Wall Overlapping Bucket Elevator, 2009

Equipment Overview
This is a Deamco BEM‑09P‑SW‑X1 solid‑wall overlapping bucket elevator, built October 2009. Proven design for gentle, sanitary conveying of powders, granules, or food‑grade products. At 20′ vertical rise and rated ~560 CFH at 75% bucket fill, it delivers medium throughput in minimal footprint. Well‑constructed in painted/stainless frame with dual Sumitomo drive motors. Currently clean and structurally sound.

Key Features and Specifications
– Model: BEM‑09P‑SW‑X1 (Solid Wall, S configuration, X‑Series)
– Discharge Height: ~20′ vertical
– Capacity: ≈560 cubic feet/hour @ 75% bucket fill
– Electrical: 240/480 V, 3‑phase, 60 Hz (two 1 HP Sumitomo motors)
– Buckets: overlapping design, plastic white buckets on dual‑chain drive
– Build: painted stainless steel/steel frame, date stamped Oct 2009
– Other: modular build, sanitary design per OEM X‑Series spec
