Excitech AM-34 5′ x 10′ Vacuum Table CNC Router, 2014

Name: Excitech AM-34 5' x 10' Vacuum Table CNC Router, 2014
SKU: 11821831253

$15,900.00

Excitech AM-34 5' x 10' Vacuum Table CNC Router, 2014 - Image 2

Excitech AM-34 5' x 10' Vacuum Table CNC Router, 2014 - Image 3

Excitech AM-34 5' x 10' Vacuum Table CNC Router, 2014 - Image 4

Excitech AM-34 5' x 10' Vacuum Table CNC Router, 2014 - Image 5

Excitech AM-34 5' x 10' Vacuum Table CNC Router, 2014 - Image 6

Excitech AM-34 5' x 10' Vacuum Table CNC Router, 2014 - Image 7

Excitech AM-34 5' x 10' Vacuum Table CNC Router, 2014 - Image 8

Excitech AM-34 5' x 10' Vacuum Table CNC Router, 2014 - Image 9

Excitech AM-34 5' x 10' Vacuum Table CNC Router, 2014 - Image 10

Excitech AM-34 5' x 10' Vacuum Table CNC Router, 2014 - Image 11

Excitech AM-34 5' x 10' Vacuum Table CNC Router, 2014 - Image 12

This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:

Table size: 5′ x 10′
Table Surface: Vacuum System
Working Area:
X-Axis: 51″
Y-Axis: 96″
Z-Axis: 7″ Clearance
Traveling Positioning Accuracy:
0.05/300mm
Repositioning Positioning Accuracy: 0.05mm
X, Y Structure: Rack & Pinion Drive, Hiwin
Rail Linear Bearings
Z Structure: Ball Screw, Hiwin Rail Linear
Bearings
Max. Rapid Travel Rate: 1,260 in/min
Max. Working Speed: 787 in/min
Drive Motors – Stepper Motor: 5HP
Spindle Speed: 0 – 1800 RPM
Command Language: G Code
Operating System: DSP System
Interface: USB

Length: 144”
Width: 84”
Height: 64”
Power: 220V / 50Hz, 3PH
Weight: Approx. 3,000 lbs.

Equipped with:
Table style : Vacuum ready and ready for
connection (Vacuum not included)
Original Manual
