FMC Link-Belt Roto-Shell Drum Dryer System – With Steam Coil Chest, NECO Heater & Flexkleen Dust Collector
$149,000.00
This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:
Qty 1 – Used FMC Link-Belt Roto-Shell Drum Dryer.
1 – Drum, approximately 60” Diameter x 312” Long.
Carbon Steel.
2 – 5’ x 15” Diameter Trunnion Idlers
1 – Chain Drive, driven by a 10 HP, 3 PH., 60 HZ., 460V, 1755 RPM Gearmotor, with 38.4:1 Ratio.
1 – Support, Carbon Steel
1 – Custom Discharge Airlock, 12” Diameter x 28” Wide, driven by Baldor 3 HP 230/460V, 60 HZ., 3 PH, TEFC Motor and Hub City Gearbox, Ratio 28:1
1 – Belt Feed Section, Carbon Steel
1 – Discharge Section, Stainless Steel
1 – Feed Conveyor, 36” x 468” x 17” Sides, Pan Bottom, Carbon Steel Frame w/ 3” Full Width Flights x 12” Spacing Belt, 10” Dia. Wing Tail Pulley, 10” Dia. Head Pulley w/3/8” Lagging, 1 15/16 Bearings Head & Tail, Nord 7.5 HP TEFC 3 PH, 230/460V 60 HZ Inverter Duty Motor, Nord Hollow Shaft Gearbox, Ratio: 40.36:1
1 – Discharge Conveyor, 36” x 372” x 17” Sides, Pan Bottom, Carbon Steel Frame w/3” Full Width Flights x 12” Spacing Belt, 10” Dia. Wing Tail Pulley, 10” Dia. Head Pulley w/3/8” Lagging, 1 15/16 Bearings Head and Tail, Nort 5 HP TEFC 3 PH, 230/460V 60 HZ Inverter Duty Motor, Nord Hollow Shaft Gearbox, Ratio 40.36:1
Two Independent Air Heating Systems
Qty 1 – Used Steam Coil Chest
1 – Steam Coil Chest Adaptor to Drum Feed w/multi–Feed Ports, Stainless Steel
1 – Steam Coil Chest to New York Blower Adaptor, Carbon Steel
1 – New York Blower, 25 HP, 3 PH, 460V, 60 HZ
Qty 1 – Used NECO Air Heating System
1 – NECO Centrifugal Fan, 25 HP, 24,000 CFM
1 – NECO Centrifugal Heater, Liquid Propane, Up to 4 MBTU heat output Model 05DSH2LPH
2 – 30” Dia. 90 Deg., Galvanized Air Pipe
Qty 1 – Used FlexKleen Stainless Baghouse Style Dust Collector Model 10-7-9-30871
1 – Stainless Housing, Two Compartments 64” x 64” each, w/Vee Bottom Hopper 120” Long x 63” Wide Top x 53” Deep Side, leading to 8” Wide Bottom.
1 – 8” Dia. x 112” Long Screw Conveyor, Carbon Steel , driven by a 1 HP, 3 PH, 60 HZ, 230/460V 1725 RPM Gearmotor.
1 – Rotary Discharge Airlock Valve 10” Dia. x 12” x 12” , driven by a 3/4 HP 3 PH, 60 HZ, 230/460V 1725 RPM Gearmotor, Ratio 37.55:1
1 – New York Blower, 50 HP, 3 PH, 60 HZ, 460V 1750 RPM Motor
1 – 30” Dia. x 12.00” Straight, Galvanized Spiral Air Pipe
2 – 30” Dia. x 60.00” Straight, Galvanized Spiral Air Pipe
1 – 30” Dia. x 18.00” Straight, Galvanized Spiral Air Pipe
4– 30” Dia. x 96.00” Straight, Galvanized Spiral Air Pipe
4 – 30” Dia. 90 Deg., Galvanized Air Pipe
1 – 30” Dia. x 16” Wide Gate Valve, Galvanized Spiral Air Pipe
15 – Donaldson Custom Ultra Web SB Filters
1 – Steel Support Frame
