Framecad F325iT Roll-Forming Machine, 2014
$149,900.00
This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:
Machine Dimensions
Length: 144โณ
Width: 31.5โณ
Height: 47.2โณ
Weight: 4,012โฏlb
Decoiler capacity: 6,600โฏlb
Coil OD: 48โณ
Max. Hydraulic Oil Pressure: 180 Bar
Max. Oil Temperature: 65*C
Profile & Material Capacity
Profile width (web): 2.5โณ to 6โณ
Standard profile size: 3.5โณ
Material thickness: 0.024โณ to 0.047โณ
Performance
Max line speed: 5,740โฏft/hr
Typical output: 2,460โฏft/hr
Main drive power: 10โฏHP
Hydraulic power: 7.4โฏHP
Hydraulic reservoir: 17โฏgal
Voltage: 400โฏVAC, 3-phase, 25โฏA
Tooling & Features
Roll-forming stations: 10 auto-gauging
Punching tools (11 standard)
Printer: Dual 16-point print heads
Interface: 21.5โณ touchscreen
Software: FRAMECAD Detailer, ProDesign, Factory2
Hot-climate hydraulics: Optional for >104ยฐF
