Fulton VMP-150 150 HP 5,175 Lb/Hr Natural Gas-Fired Vertical Steam Boiler, 2018

$74,900.00

Fulton VMP-150 150 HP 5,175 Lb/Hr Natural Gas-Fired Vertical Steam Boiler, 2018
Fulton VMP-150 150 HP 5,175 Lb/Hr Natural Gas-Fired Vertical Steam Boiler, 2018 - Image 2
Fulton VMP-150 150 HP 5,175 Lb/Hr Natural Gas-Fired Vertical Steam Boiler, 2018 - Image 3
Fulton VMP-150 150 HP 5,175 Lb/Hr Natural Gas-Fired Vertical Steam Boiler, 2018 - Image 4

Request a Quote to Instantly See Pricing

Call Now

Machine Type: Boilers
Make: Fulton
Model: VMP-150
Year: 2018
Machine Location: Upon Request
Stock #: 156634

Type: Vertical Steam Boiler
Fuel: Natural Gas
Boiler Horsepower: 150 HP
Maximum Steam Output: 5,175 lb/hr
BTU Output: 5,022,000 BTU/hr
Maximum Fuel Input: 5,978,000 BTU/hr
Maximum Allowable Working Pressure (MAWP): 150 PSI
Heating Surface: 508 sq. ft.
Gas Supply Pressure: 10–138 in. W.C.
Manifold Gas Pressure: 6–10.7 in. W.C.
Electrical: 460V / 3-Phase / 60 Hz
Boiler Full Load Amps: 16A
Burner Motor: 460V / 3-Phase / 60 Hz / 14A

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
