Hardinge Conquest 42 CNC Lathe, 1989

Max Turning Diameter: 9.1″
Distance Between Centers: 13.8″
Distance Spindle to Turret: 14″
X-Axis Travel: 5.45″
Z-Axis Travel: 13.65″
Bar Capacity: 1.625”

Swing Upper Way Covers: 19.5″
Swing Lower Way Covers: 14.5″
X-Axis Traverse: 472 ipm
Z-Axis Traverse: 630 ipm

Turret Capacity: 12 Stations
Main Spindle Speed: 5,000 RPM
Sub Spindle Speed: 3,000 RPM
Live Tool Speed: 4,000 RPM
Main Spindle Drive: 10 HP
Subspindle Drive: 1.65 HP
Live Tool Drive: 1.2 HP

Electrics: 208/230 V, 3 Ph, 50/60 Hz (Control: 115 V)
Approx. Dimensions (l x w x h): 8′ x 5′ x 6′
Approx. Weight: 10,000 LB

EQUIPPED WITH:
GE Fanuc Series O-T CNC Control
