KUKA KL1000/2 Linear Track – 30 Foot

Model: KL1000/2

Track Length: 30 feet (9,144 mm)

Payload (robot tool): Up to 1,000 kg (typically designed for KUKA robots like KR1000 Titan, large payload/heavy process robots)​

Max Number of Robots/Carriages: 2 (can run 2 robots along one axis for extended automation)

Max Rated Travel: ~30,000 mm (29.9 m is max spec; your unit is full-length)

Speed (with rated payload): Up to 1.96 m/s (rack and pinion drive)

Repeatability: ±0.02 mm

Type: Floor-mounted, enclosed track

Mass (weight):

Beam: Approx. 240 kg/meter (track alone = 2,160 kg / 4,760 lbs for 9m length)

Carriage: ~350 kg/770 lbs per carriage (robot not included)

Total system with drives: typically 5,500–7,000 lbs.

Controller compatibility: KUKA KR C4 (standard), operated via KUKA smartPAD Teach Pendant​

Operating temperature: +10° to +55°C
