Okuma Multus B300-W Multi Axis CNC Lathe, 2006 – Chip Conveyor, Renishaw Probe


Request a Quote to Instantly See Pricing

Machine Type: Multi Axis Lathes
Make: Okuma
Model: Multus B300-W
Year: 2006
Machine Location: Upon Request
Stock #: 366890

Max machining diameter: 17.72″
Max swing over saddle: 24.8″
Max working distance between spindles: 35.43″
Main spindle chuck size: 10″
X-axis (cross travel of universal head): 22.83″
Y-axis (travel of universal head): 6.299″
B-axis (rotation of universal head): 225°
W-axis (sub-spindle slide): 33.46″
Main spindle bore: 3.1″
Main spindle nose: A2-8
Main spindle horsepower: 20 HP
Main spindle speed range: 50 – 3,800 RPM
Sub-spindle horsepower: 20 HP
Sub-spindle speed range: 38 – 5,000 RPM
Automatic tool changer capacity (atc): 60 Total
Live tooling horsepower: 15 HP
Live tooling speed range: 90 – 6,000 RPM
Approximate machine dimensions: 166″ x 90″
Approximate machine height: 102″
Approximate machine weight: 24,000 LBS
Control: OSP-200L

Equipped With:

Think Multi-Functional Software
Collision Avoidance Programming
Twin Opposed Spindles
Full C-Axis On Both Spindles
Toolsetter On Both Spindles
7-Axis Live Milling
HSK-63 Taper
Chip Conveyor
Renishaw Probe

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
