Orion MA55-577 Automatic Rotary Arm Stretch Wrapper System, 1995

Rotation Speed: 0-14 RPM
Capacity: 40 loads per hour
Max Load: 48″ x 48″ x 80″ (67″ Diagonal), 4,000 lbs
Film: 30″ width 10″diameter 3″core powered pre-stretch film, 200% pre-stretch level
Rotation System: Variable Speed 90 VDC SCR Controller, 114.5″ rotation diameter
Film Carriage Lift System: Variable Speed 90 VDC SCR Controller
Type: Rotary Arm
Structure: Gantry
Controls: Automatic, Allen-Bradley SLC-500 PLC
Cut & Seal: Automatic clamp, cut, and wipe
Pneumatic Requirements: 80 PSI
Electrical Requirements: 115/230V, 1P, 60Hz
Dimensions: 122″ x 132″ x 131″
Gravity Conveyors: 6 Pieces, totaling in 346 1/4″ in length, 61 1/2″ width, 50″ track width.
