Palmary OCD-3260 CNC OD Grinder, 2020 -Touch Probe, Swing Down ID Attachment, Mag/Paper Filtration
Palmary OCD-3260 CNC OD Grinder, 2020 -Touch Probe, Swing Down ID Attachment, Mag/Paper Filtration - Image 2
Palmary OCD-3260 CNC OD Grinder, 2020 -Touch Probe, Swing Down ID Attachment, Mag/Paper Filtration - Image 3
Palmary OCD-3260 CNC OD Grinder, 2020 -Touch Probe, Swing Down ID Attachment, Mag/Paper Filtration - Image 4
MJS
48476668716

Palmary OCD-3260 CNC OD Grinder, 2020 -Touch Probe, Swing Down ID Attachment, Mag/Paper Filtration

$169,900.00

Palmary OCD-3260 CNC OD Grinder, 2020 -Touch Probe, Swing Down ID Attachment, Mag/Paper Filtration
Palmary OCD-3260 CNC OD Grinder, 2020 -Touch Probe, Swing Down ID Attachment, Mag/Paper Filtration - Image 2
Palmary OCD-3260 CNC OD Grinder, 2020 -Touch Probe, Swing Down ID Attachment, Mag/Paper Filtration - Image 3
Palmary OCD-3260 CNC OD Grinder, 2020 -Touch Probe, Swing Down ID Attachment, Mag/Paper Filtration - Image 4

Request a Quote to Instantly See Pricing

Call Now

Machine Type: Grinders
Make: Palmary
Model: OCD-3260
Year: 2020
Machine Location: Upon Request
Stock #: 668716

Distance Between Centers: 23.62″
Swing Over Table: 12.60″
Max. External Grinding Diameter: 11.81″
X-Axis Max. Stroke: 10.24″
Z-Axis Max. Stroke: 26.18″
X-Axis Rapid Feed Rate: 32.81 Ft/min
Z-Axis Rapid Feed Rate: 32.81 Ft/minMin.
Input Increment: 0.00004″ (Or 0.000004″ In Fine Mode)
Max. Grinding Wheel Outer Diameter: 16″
Grinding Wheel Width/Thickness: 2″ To 3″
Grinding Wheel Inner Diameter (Bore): 5″
Wheel Speed: 1783 Rpm
Max. Load Between Centers: 220.46 Lbs
Net Machine Weight: 7936.64 Lbs

Equipped With:
Fanuc 0i-TF Plus CNC Control
Touch Probe
Swing Down ID Grinding Attachment
Magnetic / Paper Coolant Filtration System
All Available Manuals

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
