Printed Circuit Board Manufacturing Equipment Line, 2020 – Never Used!

$74,990.00

This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:

Electric Metal Cutter
-Cut Width: 1300mm
-Cut Thickness: 0.5-3.2mm
-Electrical Requirements: 380V, 60Hz
-Dimensions: 80” x 29.5” x 41.3”
-Weight: 772 lbs

Exposure Machine for Screen Board
-Lamp: 3KW x 1set, can use 800-1000hours
-Glass Table Size: 1200mmx1500mm
-Max Silk Screen Board Size: 1000x1300mm
-Uniformity: >80%
-Exposing Time: 40-90 seconds
-Cooling System: Blower Air
-Electrical Requirements: 380V, 60Hz
-Dimensions: 55” x 61” x 49.2”
-Weight: 660 lbs

Single Side Brushing/Drying Line
-Working Width: 700mm
-Working Height: 925mm
-Board Thickness: 0.2-3.2mm
-Board Size Range: 80-600mm x 100-1200mm
-Electrical Requirements: 380V, 60Hz
-Brushing Part:
– Single Brushing & Oscillation System
-Brush Size: 320# 320# 500#
-Motor: 1.5KW, 3sets
-Oscillate motor: 200W*1set
-Acid Rinse + Pump Rinse:
-Motor: 1.1KW*4sets
-Double Spraying Rinse
-Drying Part:
-Material: 1.5mm Steel plate
-Blower: 950W*2sets
-Air knife: 4 PCS for top,4pcs for bottom
-Heater: 2KW X 3 pieces
-Thermostat: Digital thermostat and overheating protection device
-Dimensions: 280” x 68.9” x 71”
-Weight: 7,700 lbs

Screen Printing Machine
-Max Print Size: 800x1500mm
-Max Screen Frame: 1100*1300mm
-Print Thickness: 0-180mm
-Repeatability: 0.03mm
-Air Pressure: 0.5-0.6bar
-Air Consumption: 35L/Min
-Print Speed: 850 times/hour
-Electrical Requirements: 380V, 60Hz
-Dimensions: 76.8” x 53.1” x 75”
-Weight: 1,980 lbs

Single Etching/Rinse Drying Machine
-Effective Width: 700mm
-Conveyor Height: 900mm
-Etching + Ammonia Rinse:
-Working Length: 1500mm + 800mm
-Single Spraying with Oscillation system
-Pump: 4KW x 2sets
-Heater: Titanium,6KWx1pc
-Cooling: Titanium pipe,1 group
-Pressure Rinse Part:
-Rinse Length: 1200mm (2 units)
-1.1KW motor * 4sets
-Stripping Part:
-Working Length: 1500mm
-Double Spraying
-Pump: 4KW x 2sets
-Heater: Titanium,6KWx1pc
-Drying Part:
-Material: 1.5mm Steel plate
-Blower: 950W*2sets
-Air knife: 4pcs for top,4pcs for bottom
-Heater: 2KW X 3 pieces
-Electrical Requirements: 380V, 60Hz
-Dimensions: 350” x 65” x 67”
-Weight: 9,900 lbs

UV Curing Machine
-Belt Size: 600mm W x 1500mm L
-Conveyor Belt: Stainless Steel Belt 3000*2*800mm
-UV Light: 5.6KW * 2 pcs
-Conveyor Speed: 0-13 m/min
-Exhaust Fan Motor: 750W *2sets
-Machine Body Material: 1.5mm Steel with painting
-Electrical Requirements: 380V, 60Hz
-Dimensions: 120” x 40” x 71”

Drying Oven
-Temperature: 0-200°C
-Inside Drying: Hot Air Circulation Blower: 1.5KW
-Inside Dimensions: 1100mm x 1000mm x 1600mm
-Inside Material: Galvanized Sheet
-Electrical Requirements: 380V, 60Hz
-Dimensions: 63” x 47” x 91”

Developer/Rinse/Drying Machine
-Working Width: 700mm
-Conveyor Height: 900mm
-Transport Speed: 0-6 M/Min
-Developing Area:
-Developer Length: 2000mm
-Single Spraying with Oscillation System
-Pump: 4KW x 2sets
-Heater: Titanium,6KWx1pc
-Cooling: Titanium pipe,1 group
-2 Stage Rinse Part:
-Rinse Length: 1000mm
-2.2KW motor * 2 sets
-Drying Part:
-Length: 1500mm Include blower drying + heating drying
-Blower: 950W,2 sets
-Air knife: 4 PCS /top,4pcs /bottom
-Heater: 3KW*2PCS
-Electrical Requirements: 380V, 60Hz
-Dimensions: 256” x 65” x 67”
-Weight: 5,500 lbs

V-Cutter Machine
-Cutting Width: 75-480mm
-Cutting Pitch: 15-480mm
-Cutting Thickness: 1.0-3.2mm
-Cutting Speed: 7.5m/minute
-Knives to be Positioned: 1-10 knives
-Machine Material: Stainless Steel
-Dimensions: 31.1” x 27.2” x 59”
-Weight: 617 lbs

Screen Stretcher Machine
-Max Screen Stretch Size: 1200 x 1500mm
-Min Screen Stretch Size: 600 x 600mm
-Max Tension: >30N/cm
-Turbine Device: Taiwan Imported Turbo Worm Gearbox Connection Drive
-Machine Material:
-The Girder adopts 120mm x 80mm steel welding
-The collect is made of high-quality aluminum
-Machine is coated by painting
-Dimensions: 59” x 75” x 29.9”
-Weight: 617 lbs

Many Ancillary Pieces
-(1 Unit) Tray for Etching Equipment
-(300 pieces) Aluminum Substrate 1.6*1000*1200m/35um/1W
-(100 kg) LED While Solder Mask Ink
-(50 kg) Character Ink
-(100 kg) UV Ink
-(1 unit) Aluminum Screen Frame 650X1200mm
-(1 Roll) Screen Cloth for UV Ink 120T # 1270mm x 50m
-(1 Roll) Screen Cloth for LED Solder Mask 77T # 1650x50m
-(30 kg) Photosensitive Ink for making Screen Board
