Scotchman 315HTRFA Cold Saw, 1997

$13,900.00

Request a Quote to Instantly See Pricing

Call Now

Machine Type: Cold Saws
Make: Scotchman
Model: 315HTRFA
Year: 1997
Machine Location: Oregon
Stock #: 668010

Source: https://www.normanmachinetool.com/product/scotchman-automatic-non-ferrous-cold-saw-cpo-315-hfanf/

Specifications:

Capacity:
Round Tube: 3 1/2″
Square Tube: 3 1/8″
Round Solid: 1 3/4″
Square Solid: 1 1/2″ x 1 1/2″
Length Tolerance: +/- 0.006″ per index
Squareness Tolerance: +/- 0.002″ per diameter
Min. Cut Length: 1/8″
Max. Cut Length:
Single Index: 30″
Double Index: 60″
Triple Index: 90″
Cutting Speed: 3,000 RPM
Max. Blade Diameter: 12 1/2″
Air Pressure: 90 lbs. Min.
Arbor Bore: 1 1/2″
Pin Spacing: 4 / 12 / 64

Standard Features:
Fully automatic cycle
Push button controls actuate the complete cycle
5 HP – 3,000 RPM
Interlocking safety hood
Clamping both sides of blade – highest quality, burr free cuts
Mist coolant
Adjustable stroke control on the saw head
Adjustable down feed control on the saw head for feed rate
Piece counter
Length scale in both inch and metric
Quick and easy fine adjustment of length setting
One saw blade
One gallon of coolant

Mechanical Specifications:
Dimensions: 100″ x 44″ x 64″ H
Shipping Weight: approx. 1,770 lbs.

Equipped with:
12 ft. Bar Loader

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
