TwinHorn VP-1500 CNC VMC, 2006 – 4th Axis, Rotary Table, Fanuc Control


Request a Quote to Instantly See Pricing

Machine Type: Vertical Machining Centers
Make: TwinHorn
Model: VP-1500
Year: 2006
Machine Location: California
Stock #: 314687

X-Axis: 59″
Y-Axis: 23.60″
Z-Axis: 23.60″
Spindle nose to table surface: 29.52″
Spindle center to z axis rail surface: 25.59″
Z-Axis rail surface to table center: 37.40″
X,Y,Z axis rapid feed: 787.40 IPM
Cutting feed: 31.49 IPM
Ballscrew diameter & pitch: D40 x P10
Table size: 62.99″ x 23.62″
Max permissible loading: 800kg
T-slot number: 5
Spindle drive method: Belt Driven
Spindle taper: #40 (BT / CAT / DIN)
Spindle speed: 6000 RPM
ATC: 24
Machine weight: 20,283 lbs
Dimensions: 150″ x 123″ x 107″

Equipped with:
Wired for 4th axis
Fanuc Oi-MC control

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
