Usach 200 OD-L Dual Wheel CNC Grinder, 2014 – 42″ Swing, 80″ Centers, Probing, Fanuc, Fabric Filter, Chiller

Max Grinding Wheel Diameter/Face: 30″ (760mm) x2 OD Wheel Heads
Max Swing Diameter: 42″ (1,066mm)
Distance Between Centers: 80″ (2,000 mm)
Max Workpiece Weight: 3,500 lbs (1,588 kg)

Electrical Requirements: 480 V; 3 Ph; 60 Hz
Approx Grinder Weight: 20,000 lbs

EQUIPPED WITH:
Fanuc CNC Control
Indexing Grinding Wheel Heads x2
Wheel Balance System
Crush Form Dresser
Tail Stock
Head Stock
Renishaw Probing System- MP250
Barnes Fabric Filtration Unit
Chiller Unit
Available OD Grinding Wheels
Approx 5,300 Operating Hours
