VACUDEST L 8000 – Vacuum Distillation for Wastewater & ZLD – 2023 System

8000 m³/year

Specifications:
Classification: CE-Certification (not UL)
Effective power:        60 kW
Power connection:      480 V / 60 Hz
Fuse protection:        250 A
Compressed air supply: 6 bar oil-free, dried, filtered
Dimensions (LxWxH): 3390x2180x3400 mm
Empty weight:         5870 kg
Ambient temperature:    7 °C – 35 °C

Composition of the industrial wastewater to be processed:
Chloride concentration: < 10 g/l in the residue
(with modifications < 20 g/l)
Settleable substances:  < 2 ml/l
Floating oils:         7 (in distillate and residue)
Temperature:        7 °C – 35 °C
