Wilden AODD Pump 2″ Pro-Flo Pump, 2020

$7,990.00

Request a Quote to Instantly See Pricing

Call Now

Machine Type: Pumps
Make: Wilden
Model: P8/PKAPP/TWS/TF/PTV
Year: 2020
Machine Location: New York
Stock #: 129753

Series: Pro-Flo
Product Model: P8
Connection Outlet Size: 2″ (51 mm)
Connection Inlet Size: 2″ (51 mm)
Wetted Path Material: Polypropylene
Construction: Clamped
Backup Diaphragms Material: Santoprene
Connection Type: ANSI
Diaphragm Design: Full Stroke
Diaphragm Flow Capacity: Full Stroke
Max Flow Capacity: 148 gpm
Valve Balls: PTFE
Seats Material: Polypropylene
Seats Seal: FKM Encapsulated PTFE
Differential Pressure Ratio: 1:1
Max Air Inlet Pressure: 125 psi
Max Solid Size: 1/4″ (6 mm)
Lower Temperature Limit: 40 F
Upper Temperature Limit: 175 F
Primary Diaphragms Material: PTFE
Product Weight: 75 lbs (33.75 kg)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
