7/8″ Winton OB23 CNC Orbital Tube Bender, 2015 – Tooling Included

$39,900.00

This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:

Standard Equipment:
∙ Three (3) Axis CNC Control Operating From a Windows 8®PC
∙ CNC wipe bending process allows for minimum straight lengths between bends
∙ Electric Powered Servo Bend Head (A axis) with programmable speed control
∙ Electric Powered Servo for L axis and R axis with programmable speed control
∙ Pneumatic Powered Clamp and Wipe Dies with over-center locking mechanisms
∙ Swing Arm Safety Guard Located On Bend Head For Safe Machine Operation
∙ Dual Plane Straightener Assembly Mounted On Blanchard Ground Plates
∙ CW (RH) Bend Arm Rotation
∙ Chipless type cutoff system provides for accurate tube cutting
∙ Windows 8 PC user interface and two E stops for safe machine operation
∙ Payoff used to support a bulk spool of tubing, non-powered
∙ Laser Scanner & E Stop For Safe Machine Operation
∙ Electric Servo Controlled Hitch Feed (L axis) for Accurate Length Positioning
∙ X,Y,Z To L,R,A Conversion
∙ 3D Part Viewer Allows For Verification of LRA Bend Data Before Bending
∙ Springback Compensation
∙ Safety Laser Scanner

Standard Features/Specifications:
Maximum # of Bends: Maximum 64 Bends Per Part
Machine Capacity: Ø1/8 – Ø7/8 x .05 Wall Copper
Machine Repeatability: Length ± 0.004”, Rotation ± 0.25°, Angle ± 0.1°
Minimum DBB: .50” (distance between bends)
Max Speeds; L:R:A: 18”/Second: 90°/Second: 135°/Second
Min/Max Bend Radius: 0.50”/2.20” Centerline Radius / (1.5D of bend)
Maximum Part Length: Unlimited
Maximum R Axis Rotation: ± 200°
Input (Mains) Power: 208/220 VAC, 50/60Hz, Single Phase
Operator’s Manual: English – flash drive with electronic copy (.PDF)
Pneumatic Pressure: 80 psi minimum
Control Panel/Display: High Resolution Color Display
Working Height: 38.5”
Machine Dimensions: 32” wide x 105” long x 51” tall
Machine Weight: 2200 pounds

Equipped with:
Tooling
∙ 14 roll dies
∙ Two backup cams and one cutter cam
∙ Three clamp assemblies
∙ One cut head tube guide
∙ One bend die, One wiper die, one clamp die, and one bend head tube guide
Additional Bend Die
Bend die for 5/32”(.156”) OD x 7/16” CLR (.437”)

Software Options:
Multi-Program Capability
Single Step Mode
Allows a user to single step thru a program. This feature can be helpful when trouble shooting a bent profile
