10 HP Ajax SRNG-10 High Pressure Steam Boiler – Includes Reverse Osmosis Filtration System

Model #: SRNG-10
Min. Relief Valve Capacity: 346
Max BTU/Hr Input: 420,000 / Min BTU/Hr Input: 336,000
BTU/Hr Output: 336,000 / Min BTU/Hr Output: 268,800
HP: 10
Heating Surface: 62
Gross E.D.R. : 1,400
M.A.W.P.: 150 PSIG
120v 60hz,1ph, 12 Amps
Min Gas Pressure: 7 In. W.C. / Max Gas Pressure: 14 In. W.C.
Manifold Pressure: 4 In. W.C.
Fuel Type: Natural Gas
Minimum Clearance: 48” H, 36” Deep, 36” Wide
