40 Ton Tempest Inc. LTAC-40-D Cold Water Process Chiller System, 2015

$99,900.00

40 Ton Tempest Inc. LTAC-40-D Cold Water Process Chiller System, 2015
40 Ton Tempest Inc. LTAC-40-D Cold Water Process Chiller System, 2015 - Image 2
40 Ton Tempest Inc. LTAC-40-D Cold Water Process Chiller System, 2015 - Image 3
40 Ton Tempest Inc. LTAC-40-D Cold Water Process Chiller System, 2015 - Image 4
40 Ton Tempest Inc. LTAC-40-D Cold Water Process Chiller System, 2015 - Image 5
40 Ton Tempest Inc. LTAC-40-D Cold Water Process Chiller System, 2015 - Image 6
40 Ton Tempest Inc. LTAC-40-D Cold Water Process Chiller System, 2015 - Image 7
40 Ton Tempest Inc. LTAC-40-D Cold Water Process Chiller System, 2015 - Image 8
40 Ton Tempest Inc. LTAC-40-D Cold Water Process Chiller System, 2015 - Image 9
40 Ton Tempest Inc. LTAC-40-D Cold Water Process Chiller System, 2015 - Image 10
40 Ton Tempest Inc. LTAC-40-D Cold Water Process Chiller System, 2015 - Image 11

Request a Quote to Instantly See Pricing

Call Now

Machine Type: Chillers
Make: Tempest Inc.
Model: LTAC-40-D
Year: 2015
Machine Location: Upon Request
Stock #: 157559

125-HP Compressors, 3500 RPM,
460v, 3-Ph, 60Hz,
Fans 2-HP, 1140 RPM, 3-Ph, 60Hz,
Control Circuit 3 KVA,
Short Circuit Current 100KA RMS Symmetrical 600V Max.
MWP: Hi Side 400, Low Side 275,
Refrigerant: R507,
Refrigerant Charge Weight 200 lbs.
Each, Oil Type SOLEST 170,
Service Fluid 63% Ethylene Glycol,
Flow 127 GPM, Inlet Temp: -30F, Outlet Temp -40F,
Nominal Tons 40,
Evaporator: Carbon Steel Shell Tubes.
Condenser Blygold Coated Copper Coil With Aluminum Fin

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
