55 Ton Edwards Ironworker, 2020

PUNCH
Rating: 55 Tons
Max Capacity: 1-1/16″ Dia in 5/8″ A36
Stroke: 1-1/4″
Throat Depth: 7-1/2″
Open Height: 8-1/8″
Shut Height: 6-7/8″
Work Height: 36-9/16″

ANGLE SHEAR
Max Capacity:
3″ x 3″ x 3/8″
4″ x 4″ x 1/4″
Work Height: 39-7/8″

FLAT BAR SHEAR
Max Capacity:
3/8″ x 14″
1/2″ x 12″
3/4″ x 4″
Max Round: 7/8″
Max Square: 7/8″
Work Height: 34-1/2″

OPEN STATION
Throat Depth: 11-3/16″
Open Height: 8-1/8″
Shut Height: 6-7/8″
Stroke: 1-1/4″
Work Height: 34-1/2″

OPTIONAL COPER NOTCHER
Max Capacity: 2-1/2″ x 4″ x 5/16″
Work Height: 39-1/2″

Motor: 5 HP – 460 Volts / 3 Phase

DIMENSIONS
Height: 55-1/4″
Width: 44-3/8″
Depth: 36-1/8″
Shipping Weight: 2480 lb

Equipped With:

Four Available Workstations
E-Stop/Lockout-Tagout
Universal Open Tooling Station
Electric Stroke Control
