Hardinge Bridgeport XR760 VMC, 2010 – Chip Blaster System, Big Plus Spindle, Mist collector

$19,900.00

Request a Quote to Instantly See Pricing

Call Now

Machine Type: Vertical Machining Centers
Make: Hardinge
Model: xr760
Year: 2010
Machine Location: Michigan
Stock #: 913301

Control Fanuc 18i-M
X Axis Travel 30”
Y Axis Travel 24”
Z Axis Travel 24”
Table Size 35” x 23.6″
Max. Table Load 2,000 Lbs.
Spindle To Table Surface 3.94” – 27.9”
Spindle Motor 25 HP
Spindle Speeds 12,000 RPM
Spindle Taper CT 40
ATC 48 Tools Bidirectional Side Mount
Rapids (XY/Z) 1,692/ 1,417 IPM
Machine Dimensions (Approx.) 155” x 92” x 92”
Machine Weight (Approx.) 16,000 Lbs.

Equipped With:
Fanuc 18i-M CNC Control
12,000 RPM BIG-PLUS Spindle
Chip Conveyor
Chip Blaster For Through Spindle Coolant
Rigid Tap
External Hydraulic Unit
Mist Collector
3 Stage Coolant Filter

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
