Johnston Boiler Co. PFTA800-4-200S Natural Gas Boiler, 1993

$79,900.00

This product is no longer available. For additional information, please fill out the form below.

Horsepower: 800
Steam Storage: 158.7 ft³
Steam Disengaging Area: 133.4 ft²
Total Heating Surface: 4,041 ft²
Furnace Outside Diameter: 49.5 in
Furnace Heat Release Rate: 158,000 Btu/ft³ (hr)
Total Combustion Volume: 267.5 ft³
Total Heat Release Rate: 120,000 Btu/ft³ (hr)
Water Content N.W.L.: 4,366 gal
Water Content Flooded: 5,553 gal
Approx. Dry Weight 15#: 53,500 lb
Approx. Operating Weight 15#: 89,800 lb
Approx. Dry Weight 150#: 58,000 lb
Approx. Operating Weight 150#: 94,300 lb
Approx. Dry Weight 200#: 62,100 lb
Approx. Operating Weight 200#: 98,400 lb
Approx. Dry Weight 250#: 65,400 lb
Approx. Operating Weight 250#: 101,700 lb
Approx. Dry Weight 300#: 70,500 lb
Approx. Operating Weight 300#: 106,800 lb

*More Technical Specificaitons Availble Upon Request*
