Leadwell LTC-30BPL Long Bed CNC Lathe, 1999 – Tailstock, Chip Conveyor, Tool Presetter, Fanuc OT

Name: Leadwell LTC-30BPL Long Bed CNC Lathe, 1999 - Tailstock, Chip Conveyor, Tool Presetter, Fanuc OT
SKU: 15787599137
Availability: InStock

$16,900.00

Request a Quote to Instantly See Pricing

Call Now

Machine Type: CNC Lathes
Make: Leadwell
Model: LTC-30BPL
Year: 1999
Machine Location: Upon Request
Stock #: 599137

Swing Over Bed: 25.6″
Distance Between Centers: 40.0″
Max. Machining Diameter: 18.9″
Max. Machining Length: 60″
Chuck: Hydraulic 3-Jaw 12″
X-axis Travel: 10.4″
Z-axis Travel: 40.2″
Spindle Speed: 2500 Rpm
Bar Capacity: 3″
Spindle Nose: A2-8
# Of Tool Positions: 12
Rapid Feed Rate: X-axis: 393 Ipm
Rapid Feed Rate: Z-axis: 472 Ipm
Tail Stock Quill Diameter: 4.33″ (5MT)
Tailstock Quill Stroke: 4.92″
Main Motor: 35 Hp

Equipped With:
Fanuc OT Control
Tailstock
Tool Setter
Chip Conveyor
Long Bed

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
