Makino EDNC6 CNC Sinker EDM, 2015 – C-Axis Head, 16 Tool Changer

Work tank size: 43.3″ x 29.5″ x 17.7″
Table size: 31.5″ x 21.7″
X-axis Travel: 25.6″
Y-axis Travel: 17.7″
Z-axis Travel: 13.8″
Tools: 16

Max electrode diameter: 3.15″ / 7″
Max electrode length: 10.2″
Max electrode weight: 220 lbs.
Max fluid level: 15.7″
Max workpiece weight: 3300 lbs.
Platen to table: 27.5″
Power supply: 60 Amps (80 Peak)
Rapid traverse rates: 78 IPM

EQUIPPED WITH:
Makino Hyper I CNC Control
MR Head with Full C-Axis
Erowa Auto Chuck
16 Tool Changer
Remote Jog Handle
Filtration System
Chiller Unit
Available Erowa Tooling

Approx 8,600 Hours
