Mazak FH-5800 500mm HMC, 1999 – Full 4th, Mazatrol 640T, Coolant Thru

$26,900.00

Request a Quote to Instantly See Pricing

Machine Type:
Horizontal Machining Centers
Model:
FH-5800
Make:
Mazak
Year:
1999

SPECIFICATIONS:

X-Axis Travel: 27.95″
Y-Axis Travel: 24.02″
Z-Axis Travel: 25.98″
Pallet Size: 19.68″ x 19.68″
Max Weight of Workpiece:1,100 lbs
Table Indexing FULL 4TH AXIS
Spindle Center To Table Top :1.96″ -25.98″
Spindle Nose To Table Center :5.91″ – 31.89″
Spindle Motor: 30 HP
Spindle Taper: CAT 40
Spindle Speeds: 12,000 RPM
Rapid Traverse Rate X,Y,Z: 1,968 IPM
ATC :80
Max Tool Length: 14.17″
Max Tool Diameter: 5.740″
Max Tool Weight: 26 lbs
Machine Weight: 27,400 lbs

EQUIPPED WITH:
Mazatrol PC-Fusion 640M Control
Full 4TH AXIS
Coolant Thru Spindle

(2) Pallet Changer
Chip Conveyor

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
