Okamoto PSG-208 CHiQ CNC Double Column Surface Grinder, 2012

$299,900.00

Request a Quote to Instantly See Pricing

Machine Type: Grinders
Make: Okamoto
Model: PSG208CH-iQ
Year: 2012
Machine Location: Upon Request
Stock #: 155336

Grinding Capacity: 40″ x 80″
Maximum Pass Width: 36″
Maximum Distance under Wheel: 23.0″
Standard Magnetic Chuck Size: 32″ x 79″
Table Load Capacity (including chuck): 5,512 lbs.
Maximum Longitudinal Travel: 89″
Longitudinal Feed Rate: 6~98 ft./min.
Maximum Cross feed Travel: 36″
Minimum Cross feed Increment: 0.0001″
Maximum Cross feed Rapid Feed: 235 IPM
Maximum Vertical Feed Travel: 24.4″
Minimum Vertical Feed Increment: 0.00001″
Maximum Vertical Rapid Feed: 23.0″ IPM
GRINDING WHEEL:
Dimensions (DxWxB): 20″x4″x8″
Speed: 400 – 1,600 rpm/60Hz.

Okamoto iQ Control, (2) Axis, 9.0″ Display
Automatic Setting of Process Condition
Hand held Pulse Generator
Shift Plunge Grinding Cycles
Rough / Fine Grinding Cycles
Table Guide Way V & V with Precision Scraping
Touch Screen Software w/ Teach Input Positioning
30 HP Grinding Wheel Spindle Motor w/ Load meter
Invertor System for Grinding Wheel Spindle
Over-the-Wheel Dresser with Dress Compensation
Table Mounting Dresser
Enclosed Table with Open Top
Hydraulic Temperature Controller
Rapid Wheel Head Approach and Retract

Floor Space: 259″x152″x140″
Net Weight: 34,200 lbs.

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
