Studer Favorit CNC Cylindrical Grinder, 2017 – LOW HOURS, Fanuc Control
$198,500.00
This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:
X-Axis Travel: 11.2โณ
Max Travel Speed X: 394โณ/min
Z-Axis Travel: 31.5โณ
Max Travel Speed Z: 787โณ/min
Swiveling Range B: 210 deg
Swiveling Range C: โ deg
Max Spindle Power: 12 hp
Max Number Of Revolutions: 2โ810 rpm
Max Grinding Wheel Diameter: 20โณ
Max Grinding Wheel Width: 3.15โณ
Workpiece Length: 40โณ
Workpiece Diameter:13.75โณ
Max. Workpiece Weight: 176 lbs
Distance Between Centers: 25.6โณ
Center Height: 6.9โณ
Tailstock:
Taper: MT4
Travel of Barrel: 1.38โณ
Diameter of Barrel: 1.97โณ
Approx. Weight: 12,000 lbs
Dimensions for Placement: 12′ x 5′ x 9′
Dimensions for Transport: 18′ x 5′ x 9′
Dimensions of Accessories for Transport: 8′ x 8′ x 8′
Equipped With:
Fanuc Series 0i-TD Control
Mist Buster
A Norton O.D. Wheel
Two Brand New Wheel Holders & Various I.D. Grinding Wheels & Misc. Consumables
