36″ Bullard Dyn-au-tape CNC Vertical Turret Lathe – Allen Bradley Control

$24,900.00

Request a Quote to Instantly See Pricing

Machine Type: Vertical Turret Lathes
Make: Bullard
Model: Dyn-Au-Tape VTL
Year: 0000
Machine Location: Florida
Stock #: 058377

Table Size: 36″ – 4 Jaw Chuck
Swing – with Side Head in Working Position: 40”
Swing – with Side Head Below Table: 48”
Distance Under Rail: 50” Maximum
Rail Adjustment – Vertical: 37 3/4”
Table Speeds (20): 6 to 225 RPM
Feeds (16): .001” to .250”
Turret Head: 5 Position with 2” Holes
Turret Head Adjustment: 30 Degrees – Left or Right
Turret Head Stroke: 26”
Turret Head Horizontal Adjustment on Rail: 46”
Maximum Distance – Turret Face to Table:
Side Head: 4 Position – 24” Stroke
Side Head Vertical Travel: 39 1/2”
Side Head Horizontal Travel: 24″
Allen Bradley Control

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
