5000W Trumpf TruLaser 3050 CO2 Laser, 2007 – 5′ x 10′ Table, TruFlow 5000

Name: 5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000
SKU: 58025059248

$79,900.00

5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000 - Image 2

5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000 - Image 3

5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000 - Image 4

5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000 - Image 5

5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000 - Image 6

5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000 - Image 7

5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000 - Image 8

This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:

X-Axis: 120″
Y-Axis: 60″
Z-Axis: 4.5″
Laser Output Power: 5,000 Watts
Max Workpiece Weight: 1,984lbs
Max Positioning Speed: 7,874 IPM
Simultaneous Speed: 11,811 IPM
Positioning Accuracy: ± 0.004″
Mild Steel Cutting Capacity: 1″
Stainless Steel Cutting Capacity: 0.75″
Aluminum Cutting Capacity: 0.5″
Beam-On Hours: 33,122

Approximate Machine Dimensions: 36.9′ x 15.1′ x 7.9′
Approximate Machine Weight: 26,455lbs

Equipped With
Siemens Sinumerik 840D CNC Controller
TruFlow 5000
Trumpf LiftMaster Automated Loading/Unloading System
