5000W Trumpf TruLaser 3050 CO2 Laser, 2007 – 5′ x 10′ Table, TruFlow 5000

$79,900.00

5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000
5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000 - Image 2
5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000 - Image 3
5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000 - Image 4
5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000 - Image 5
5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000 - Image 6
5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000 - Image 7
5000W Trumpf TruLaser 3050 CO2 Laser, 2007 - 5' x 10' Table, TruFlow 5000 - Image 8

Request a Quote to Instantly See Pricing

Call Now

Machine Type: CO2 Lasers
Make: Trumpf
Model: TruLaser 3050
Year: 2007
Capacity: 5000 Watt
Machine Location: Upon Request
Stock #: 059248

X-Axis: 120″
Y-Axis: 60″
Z-Axis: 4.5″
Laser Output Power: 5,000 Watts
Max Workpiece Weight: 1,984lbs
Max Positioning Speed: 7,874 IPM
Simultaneous Speed: 11,811 IPM
Positioning Accuracy: ± 0.004″
Mild Steel Cutting Capacity: 1″
Stainless Steel Cutting Capacity: 0.75″
Aluminum Cutting Capacity: 0.5″
Beam-On Hours: 33,122

Approximate Machine Dimensions: 36.9′ x 15.1′ x 7.9′
Approximate Machine Weight: 26,455lbs

Equipped With
Siemens Sinumerik 840D CNC Controller
TruFlow 5000
Trumpf LiftMaster Automated Loading/Unloading System

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
