ABB IRB-1400 Welding Robot with Miller Deltaweld 452 and Robotic Interface II Weld Controller

ABB IRB 1400 Robot
Robot Handling Reach of
capacity 5th axis : 5 kg 1.44 m

Supplementary load
on axis 3 18 kg
on axis 1 19 kg

Number of axes
Robot manipulator 6
External devices 6

Integrated signal supply 12 signals on upper arm
Integrated air supply Max. 8 bar on upper arm
PERFORMANCE
Position repeatability 0.05 mm (average result from ISO test)
Movements IRB 1400
Max. TCP velocity 2.1 m/s
Continuous rotation of axis 6

Miller Deltaweld 452
Input Hz 60 Hz
Input Phase 3-Phase
Net Height 30 in
Net Length 38 in
Net Width 24 in
Max Open Circuit Voltage 48 VDC
Net Weight 384 lbs
Rated Output 450 A at 38 VDC
