Adco MN 12WM-160-SS Wrap Around Sleever, 2012

SLEEVE STYLE:
Flat blank, wraparound with standard bottom glue sleeve
MACHINE SPEED:
Variable up to 160 sleeves per minute maximum. Actual maximum speed may vary depending on board
type, weight, density, and scoring. Following are examples of the style of finished sleeved packages.

MACHINE DETAILS:
•Heavy-duty variable frequency drive (VFD)
• Continuous motion
• Main drive overload protection
• VFD automatic infeed system controlled by product supply to stop indexing system without stopping main
machine
• 3-head rotary carton feeder
• Oilless vacuum pump
• 6′ long horizontal powered carton hopper with motorized advance (left side load)
• Side compression chains
• Screw adjustments on all axis
• Powered takeaway belts
• Captured #60 overhead chains
• 12′ long stainless steel
• Castors for portability and leveling feet
• Zinc plated cold rolled steel parts
• Barrier guarding – electrically interlocked
• Overhead lights mounted to center guard beam
• Group lubrication (cluster)
• 24vdc control voltage
• 480v/3ph/60hz electrics
• NEMA 12 electrical enclosures
• 4-color stack light with Green for machine Running, Yellow for machine waiting for product, armed and
ready to run, Red for machine Stopped (safe) and Blue for low carton hopper supply
• Jog cord with pushbutton and watertight outlet
• Category 3 electrical safety system
• NFPA 79 compliant
• Alarm buzzer for start/stop of machine with (3) second start delay
• PLC Control System with COLOR touch screen HMI (programming software optional)
• Grace Port outlet mounted on electrical cabinet door
• Carton bottom to floor elevation 36”±1” (.91m)

CLOSING SYSTEM:
• Nordson 480V ProBlue 4 glue unit with 7-day programmable timer, temperature
setback, (1) gun & hose, Saturn filter, mounting brackets, closing plow assembly,
electricals, bottom squaring chain, pressure transducer, and pattern controller
• Separate electrical disconnect for Nordson glue unit
(Nordson unit will not lose power if the electrical panel is locked out – Will need a separate power drop)
SPECIAL FEATURES:
• 15’ (4.57m) long product infeed conveyor with VFD drive
• 3-speed drive modifications controlled by photo eyes
• Dual servo driven timing screws (2-sizes)
• Digital readouts for size changes
• Overhead beam operator panel mounting (left side operator controls)
• Downstream backup detection/machine stop
• Ethernet card for networking
• Fault map of guard doors, E-stops, and overload devices on the touch screen
• UL 508A Listed Industrial Control Panel

460v
3ph
60hz
