Doosan HP-5100 Horizontal Machining Center, 2013 – Coolant Through Spindle, 170 Tool ATC
$59,900.00
This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:
Pallet Size: 19.7″ x (2)
X-Axis Travel: 33.5″ (850 mm)
Y-Axis Travel: 27.6″ (700 mm)
Z-Axis Travel: 29.5″ (750 mm)
Pallet Index: 1 Degree
Spindle Speed: 14,000 RPM
Spindle Taper: Big Plus, CAT-40 DIN 15
Spindle Motor: 22/18.5 KW
Spindle Torque: 68.7 ft. lbs.
Spindle Center to Tabletop: 2″ – 29.5″
Spindle Nose to Table Center: 5.9″ – 35.4″
Tool Storage Capacity: 170
Pallet Change Time: 7.5 Seconds
Pallet Load Capacity: 1102 lbs.
Max Workpiece Size (Dia / Height): 31.5″ / 36.6″
Max Tool Diameter: 3″ / 5.5″
Max Tool Length: 15.7″
Max Tool Weight: 22 lbs.
Power Source: 3 Ph, AC 220V, 60 Hz
Approx. Machine Dimensions (L x W x H): 194″ x 108″ x 119″
Approx. Machine Weight: 33,069 lbs.
Equipped With:
FANUC 31iA CNC Control
PC/MCIA Interface
Number of Tool Offsets 200 Pairs
Helical Interpolation
Rigid Tapping
Coolant Thru Spindle
Tool Life Management
Spindle Chiller Unit
Manual Pulse Generator
